APC Easy UPS ONLINE SRV RM Ext. Runtime 3000VA 230V with Rail kit Batt pack (SRV3KRILRK)
$1,249.00
- Part Number: SRV3KRILRK
- Lead time: Usually in Stock
- Run time for load: 2400 W
- Min-max: 240-2400 W, 12min 44s
- Max. Capacity Used: 100 %
- Main Input Voltage: 230 V
- Warranty: 2 years repair or replace
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: SRV3KRILRK
- Overview
- Presentation: High quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditions.
- Lead time: Usually in Stock
- Main
- Run time for load: 2400 W
- Min-max: 240-2400 W, 12min 44s
- Max. Capacity Used: 100 %
- Main Input Voltage: 230 V
- Other Input Voltage: 220 V, 240 V
- Main Output Voltage: 230 V
- Other Output Voltage: 220 V, 240 V
- rated power in W: 2400 W
- Rated power in VA: 3000 VA
- Input Connection Type: IEC 60320 C20
- output connection type: 6 IEC 60320 C13, 1 IEC 60320 C19
- Number of rack unit: 4U
- Number of cables: 1
- Provided equipment
- 1 IEC 60320 C19 to Schuko power cable
- 1 IEC 60320 C13 to C14 power cable
- 1 USB cable
- 1 RS-232 configuration cable
- 2 rack mounting brackets
- 2 rack mounting support rails
- 1 external battery pack
- 1 battery cable
- General
- Number of power module filled slots: 0
- Number of power module free slots: 0
- Redundant: No
- Physical
- Colour: Black (RAL 7010)
- Height: 17.2 cm
- Width: 43.7 cm
- Depth: 63.2 cm
- Net weight: 52 kg
- Mounting location: Front
- Mounting preference: Lower
- Mounting mode: Rack-mounted
- USB compatible: Yes
- Mounting position: Horizontal
- Input
- Input voltage limits: 110...285 V half load, 160...280 V full load
- Network frequency: 40...70 Hz auto sensing
- Output
- Maximum configurable power in VA: 3000 VA
- Maximum configurable power in W: 2400 W
- Output frequency: 50/60 Hz +/- 3 Hz sync to mains
- Harmonic distortion: 3 %
- UPS type: Double conversion online
- Wave type: Sine wave
- Efficiency: 88 % (full load)
- Additional information: Configurable for 220 : 230 or 240 nominal output voltage
- bypass type: Internal bypass (automatic and manual)
- Crest factor: 3 : 1
- Conformance
- Product certifications
- CE
- UKCA
- EAC
- TISI
- Standards
- EN/IEC 62040-1:2019/A11:2021
- EN/IEC 62040-2:2006/AC:2006
- EN/IEC 62040-2:2018
- Environmental
- Ambient air temperature for operation: 0…40 °C
- Relative humidity: 0…95 % non-condensing
- Operating altitude: 0...3000 m
- Ambient air temperature for storage: -20…50 °C
- Storage Relative Humidity: 0…95 % non-condensing
- Storage altitude: 0…15000 m
- Acoustic level: 50 dBA
- heat dissipation: 910 Btu/h
- IP degree of protection: IP20
- Batteries & Runtime
- Run Time: View Runtime Graph
- Efficiency: View Efficiency Graph
- Battery type: Lead-acid battery
- Battery voltage: 72 V
- Number of battery filled slots: 1
- Number of battery free slots: 0
- Battery recharge time: 5.5 h
- Battery charger power: 350 W rated
- Battery option
- SRV72RLBP-9A 1 1878 VAh
- SRV72RLBP-9A 2 2817 VAh
- SRV72RLBP-9A 3 3756 VAh
- SRV72RLBP-9A 4 4695 VAh
- Communications & Management
- Alarm: Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
- control panel: Multifunction LCD status and control console
- Surge Protection and Filtering
- Surge energy rate: 600 J
- Packing Units
- Unit Type of Package 1: PCE
- Number of Units in Package 1: 3
- Package 1 Height: 48 cm
- Package 1 Width: 60 cm
- Package 1 Length: 70 cm
- Package 1 Weight: 66.8 kg
