UPS Online Prolink 10KVA PRO810-QRS, Rack mount, LCD, Terminal, USB, RS232, PF1.0 (battery 9AHx20)2Y
- Part Number: PRO810-QRS
- Capacity: 10KVA: 10000VA / 10000W
- Battery: 9Ah or 12Ah x20
- UPS type: Rack mount
- Input phase: Single phase with ground
- Front panel: Status LED, function keys, LCD display
- Communication: Smart RS232, USB port and Emergency Power Off (EPO)
- LCD indicators: Load level, battery level, AC mode, battery mode, bypass mode, and fault
- Warranty: 2 years on part.
Contact for Price & Stock
Delivery 25 Provinces
Official Warranty
100% Genuine Product
Tech Support
Specifications
- Part Number: PRO810-QRS
- GENERAL
- - UPS Type: Rack / Tower
- - Phase: 1 phase in / 1 phase out
- - Rating (VA): 10000
- - Nominal Power (W): 10000
- - Standard Model Dimension (mm): UPS Unit: 610 x 438 x 88 [2U] (D x W x H); Battery Pack: 600 x 438 x 133 [3U] (D x W x H)
- - Weight (kg): UPS Unit: 20; Battery Pack: 63
- INPUT
- - Connection Type: Terminal
- - Nominal Voltage: 208/220/230/240 VAC VAC
- - Voltage Range: 110~300VAC ± 3% at 50% load, 176~300VAC ± 3% at 100% load
- - Frequency Range: 46~54 Hz ◎ 50Hz / 56~64 Hz ◎ 60Hz
- - Power Factor: ≧0.99
- - THDi: < 4% @100% Load, < 6% @50% Load
- OUTPUT
- - Connection Type: Terminal
- - Nominal Voltage: 208*/220/230/240 VAC
- - Voltage Regulation: ±1%
- - Frequency Range (Synchronized Range): 46~54 Hz ◎ 50Hz / 56~64 Hz ◎ 60Hz
- - Frequency Range (Batt. Mode): 50 Hz ± 0.1 Hz or 60 Hz ± 0.1 Hz
- - Current Crest Ratio: 3:1 (max.)
- - Harmonic Distortion: ≦1% THD (Linear load), ≦4% THD (Non-linear load)
- ALARM & INDICATORS
- - Battery Mode: Sounding every 4 seconds
- - Low Battery: Sounding every second
- - Overload: Sounding twice every second
- - Fault: Continuously sounding
- - LCD: Load level, Battery Level, AC mode, Battery mode, Bypass mode and Fault
- CONNECTIVITY, CONTROL & MONITORING
- - Front panel: Status LED, Function keys, LCD display
- - Communication: Smart RS232*, USB Port, Emergency Power Off (EPO)
- BATTERY
- - Standard Model Type: 12V / 9Ah
- - Numbers: 20
- - Typical Recharge Time: 9 hours recover to 90% capacity.
